Carbon Steel Air Tank

We have won the recognition of a wide range of users with its first-class product quality and first-class pre-sales and after-sales services, achieving the top positions in several aspects such as gas tank sales volume and market share in the industry. It has always been known in users for its reliable quality, timely delivery, and reasonable prices.

A Carbon Steel Air Tank is a common industrial pressure vessel used for storing compressed gases such as air, nitrogen, oxygen, natural gas, etc. Its main features and components are as follows:

1.Material:

The vessel body is primarily constructed from Carbon Steel. Carbon steel offers good mechanical strength, workability, and cost-effectiveness, making it a standard material for medium- and low-pressure vessels. To ensure corrosion resistance and service life, the interior may be coated (e.g., with epoxy), and the exterior is typically protected by anti-corrosion paint.

2.Configuration:

Vertical refers to its orientation—it is installed upright. This design has a small footprint but requires adequate foundation height. It facilitates the settling of moisture or impurities by gravity, especially in compressed air systems.

3.Core Functions:

● Storage & Buffering: Balances pressure fluctuations in the gas system, preventing frequent cycling of equipment like air compressors.

● Pressure Stabilization: Provides a steady and consistent gas pressure to downstream equipment.

● Cooling & Separation: Allows the compressed gas to cool inside the tank, promoting the condensation and separation of water vapor and oil mist, which are then discharged via a bottom drain valve.

● Emergency Reserve: Supplies gas for a short period in case of a temporary interruption in the gas supply.

4.Main Components:

● Shell and Heads: Form the primary pressure boundary, typically consisting of a cylindrical shell with elliptical or dished heads.

● Nozzles/Connections: Include inlet, outlet, safety valve connection, pressure gauge connection, manhole or handhole (for inspection and maintenance), drain port, etc.

● Safety Attachments: Essential safety devices include a Safety Valve (to prevent overpressure) and a Pressure Gauge (to indicate live pressure).

● Support: Usually a skirt or leg support to anchor the vessel to its foundation.

5.Design & Compliance:

Carbon Steel Air Tank's design, manufacturing, and inspection must strictly adhere to the pressure vessel codes and standards of the respective country or region (e.g., GB/T 150 in China, ASME BPVC Section VIII in the USA). It must be produced by certified manufacturers and undergo regular inspections.

6.Applications:

Widely used across various industries requiring gas supply and buffering, including factory pneumatic systems, air separation plants, natural gas distribution stations, energy, chemical, pharmaceutical, and food & beverage sectors.
